Lemo compatible female right angle connector 6pin 1B printed circuit board connector for back panel mounting

• Contact Type: Solder
• Max. Matings: 5000
• Contact Dia.: 0.5 mm (0.02in)
• Bucket Dia.: 0.45 mm (0.018in)
• Max. Solid Conductor: 0.09 mm^2 (AWG 28)
• Max. Stranded Conductor: 0.09 mm^2 (AWG 28)
• R (max): 8.7 mOhm
• Vtest (contact-shell): 1300 V (AC), 1840 V (DC)
• Vtest (contact-contact): 950 V (AC), 1340 V (DC)

• Temp (min / max): -55°C / +250°C
• Humidity (max): <=95% [at 60 deg C /140 F]
• Vibration: 15 g [10 Hz - 2000 Hz]
• Shock Resistance: 100 g [ 6 ms]
• Salt Spray Corrosion: >1000 hr
• Climatical Category: 50/175/21
• Shielding (min): 75 dB (10 MHz)
• Shielding (min): 40 dB (1 GHz) IP Rating: 50

• 00B sizes: 2, 3 and 4
• 0B sizes: 2 3 4 5 6 7 and 9
• 1B sizes: 2, 3, 4, 5, 6, 7, 8, 10 and 14
• 2B sizes: 2, 3, 4, 5, 6, 7, 8, 10, 12, 14, 16, 19 and 32

If you need open a machine mold, you must confirm the hole size according to your board, and then choose connector style, our connector have different sizes from 00 to 03, it can apply whole size board. For example, if your board panel cut-outs OD is about 8-9mm, you should choose 0B size.
