EXG PCB mounting connector Lemo alternative 0B / 1B / 2B 2pin rear panel installed elbow socket

• Shell Style/Model: EX.HLN*: Elbow receptacle for printed circuit (solder or screw fixing)
• With two nuts
• Suitable for printed circuit
• Keying circular (can rotate)
• Brass (nickel-plated) shell, collect nut, latch sleeve
• Contact type: printed circuit board
• Maximum matings: 5,000

• Contact Type: Print (straight)
• Contact Dia.: 1.3 mm (0.051in)
• R (max): 3.6 mOhm
• Vtest (contact-shell): 1350 V (AC), 1910 V (DC)
• Vtest (contact-contact): 1500 V (AC), 2120 V (DC)
• Temp (min / max): -55°C / +250°C
• Humidity (max): <=95% [at 60 deg C /140 F]
• Vibration: 15 g [10 Hz - 2000 Hz]
• Shock Resistance: 100 g [ 6 ms]
• Salt Spray Corrosion: >1000 hr
• Climatical Category: 50/175/21
• Shielding (min): 75 dB (10 MHz)
• Shielding (min): 40 dB (1 GHz) IP Rating: 50

If you need open a machine mold, you must confirm the hole size according to your board, and then choose connector style, our connector have different sizes from 00 to 03, it can apply whole size board. For example, if your board panel cut-outs OD is about 8-9mm, you should choose 0B size.
